Equipped with a washer and EPDM rubber layer, providing reliable and secure fastening, featuring self-tapping threads for quick penetration during installation, ensuring efficient operations.
Applications
For light duty purposeFeatures
Unique point to thread design extrudes the metal preventing strip out| Hex Washer Head Self Drilling Screw | ||||
| Size | Length / inch | Length / mm | Drill Point m/m | Drill Capacity m/m |
| #6-20 M3.5 | 3/8" | 10 | #2 | 0.5-1.0 |
| 1/2" | 13 | #2 | 0.5-1.0 | |
| 5/8" | 16 | #2 | 0.5-1.0 | |
| #8-18 M4.2 | 1/2" | 13 | #2 | 1.0-2.0 |
| 5/8" | 16 | #2 | 1.0-2.0 | |
| 3/4" | 19 | #2 | 1.0-2.0 | |
| 1" | 25 | #2 | 1.0-2.0 | |
| 1-1/4" | 32 | #2 | 1.0-2.0 | |
| 1-1/2" | 38 | #2 | 1.0-2.0 | |
| #10-16 M4.8 | 1/2" | 13 | #2 | 1.0-2.0 |
| 5/8" | 16 | #2 | 1.0-2.0 | |
| 3/4" | 19 | #2 | 1.0-2.0 | |
| 1" | 25 | #3 | 1.0-3.0 | |
| 1-1/4" | 32 | #3 | 1.0-3.0 | |
| 1-1/2" | 38 | #3 | 1.0-3.0 | |
| 2" | 50 | #3 | 1.0-3.0 | |
